Stage 4

Precision Performance And Coatings


Only 10 left!

Stage 4 (billet 3.8L/4.1L crankshaft, 1800hp/1300tq rating)

$40,000 (Key upgrades: Fully built cylinder heads with Race port, Larger camshafts, 300M rods, fire ringed shortblock, deeper 625 head studs, cylinder head modication, upgraded main girdle, 12mm main studs)


  • Disassemble and assemble long block
  • Disassemble and inspect cylinder heads
  • Race port/polish of cylinder heads
  • Install GSC High-Rev Beehive Spring and Retainer Kit (10,000 rpm rating)
  • Install GSC S4 camshafts
  • Install GSC valve stem seals
  • Install GSC +1mm Exhaust and Intake Valves
  • Billet 3.8L/4.1L polished crankshaft assembly (customer's choice)
  • Balance billet 3.8L/4.1L crankshaft assembly
  • Wash all parts for assembly
  • Pin fit of new rods and pistons
  • Assembly of 3.8L/4.1L long block
  • Manley 300M I beam rods (2,000hp rating)
  • Diamond PPC spec custom 10:1 piston set with Trend .250 upgraded wrist pins with DLC coating (2,000hp rating)
  • ARP 12mm Main stud set
  • Upgraded main girdle modifications (chromoly)
  • ARP 625 Head Stud set with deeper studs
  • Cylinder head re-enforcement modifications
  • Fire ring shortblock assembly (machine block)
  • Athena headgasket set for fire rings
  • OEM timing components (NEW)
  • OEM oil pump assembly (NEW)
  • OEM VVT camshaft gears (2) (NEW)
  • OEM water pump
  • OEM Engine gasket set
  • Dodson Front Cover oil passage gasket kit
  • Aftermarket main/rod bearings, custom fit
  • ATI Crank Damper
  • Boost Logic Deep oil pan (1.5qt capacity)
  • Powder coated engine timing/valve covers
  • (Note, build is completed using customer's existing engine in good working condition)
